“Surf” Six Bike Rack

Site Location

Frost 2090 “Surf” series steel bike racks are made of heavy duty Canadian steel with a unique and modern design. These bike racks are designed to allow for six bikes to lock to them. These are most commonly used at schools/universities, hotels, retail centers, condominiums, office buildings, city streets, and even residentially.

Features

• Unique and modern architectural appearance
• Tested to survive harsh climates
• Canadian made with heavy duty steel
• Designed for use with up to six bikes
• Can be surface mounted or imbedded in concrete

Characteristics

This bike rack has all 11 and 12 gauge hot rolled Canadian steel construction with RAL super durable TGIC-free polyester powder coating which provides rust proof finish. Tested to survive harsh summer and winter weather. The bike rack comes in black, blue, red, or green. Dimensions are: 35.1″W x 25.9″H x 26.6″D. Mounting hole diameter: 0.4″ for all four mounting holes. The unique architectural look and durable manufacturing make this a great product for many commercial and residential site locations.

Capacity

• Will hold up to six bikes

Materials

• All steel welded construction in heavy duty 11 & 12 gauge HRS
• Frost uses Super Durable TGCI-Free Powder Coat paint on all their site furnishings products. This type of powder coating is designed for superior weatherability compared to standard TGIC polyester powder coatings. This type of paint is designed to meet the AAMA (American Architectural Manufacturers Association) standard 2603. It provides excellent exterior color and gloss retention, superior over bake resistance, and good chemical resistance. The paint is designed to withstand 1500 hours of salt spray testing and 1 year of outdoor exposure in extreme conditions.
• Colours available for ring: RAL Blue 5005, RAL Black 7021, RAL Green 6018, RAL Red 3001

Product Dimensions

• 80cm W x 65.8cm H x 67.6cm D (35.1″W x 25.9″H x 26.6″D)

Product Weight

• 23.1 kg (51 lbs)

Installation

This bike rack can be mounted onto the ground with anchors (not included) or imbedded in concrete. Mounting hole dimensions: 0.4″ for all 4 mounting holes.

Maintenance

Normal preventative maintenance and cleaning will keep Frost products functioning properly and may extend normal product life. Products should be wiped down with a damp soft cloth periodically. Approved stainless steel cleaner may be used to clean scuffs or fingerprints on stainless surfaces. Do not use harsh detergents or chemical cleaners. For general dirt and blemishes on painted steel or plastic use warm water and mild soap, or a general mild cleaning solution. When using any type of cleaning solution, spray onto a discrete area to test before full usage. After the cleaning agent is applied, wipe off with a clean soft cloth or sponge.

Warranty

If any product or part proves to be defective within 12 months from date of shipment from the factory it will be repaired or replaced without any charge including freight costs when authorized. Costs resulting from the installation or removal of defective products are not covered under this warranty. Discolouration to stainless steel parts resulting from exposure to harsh environmental and / or chemicals are not considered to be defects in workmanship or material and are not covered under warranty.
