Pet Waste Station

Site Location

The 2013 complete pet waste system is perfect for any area with high traffic pet ownership. The system is designed for outdoor use in and around public parks, condominiums, residential paths, schools/universities, and common courtyard areas.

Features

• Case of 10 boxes of 200 bags (2,000 bags total per case)
• Bag dispenser which holds two boxes of bags (400 total bags)
• Waste receptacle with drainage holes
• Post which can be cemented or anchor mounted

Characteristics

The 2013 complete Frost pet waste system includes one pet waste bag dispenser, one pet waste disposal, one case of pet waste bags (10 boxes of 200 bags), and one pedestal mounting post. The dispenser is made of 18 gauge steel and finished in grey powder coated rust proof paint. It is lockable and has a capacity of two pet waste bag boxes (total capacity of 400 bags). The disposal comes with steel, rust proof mounting bracket and 100% recycled rotationally moulded polyethylene disposal bin. This bin has a 18.75 litre (5.4 US gal) capacity and includes both drainage holes and keyed tumbler lock to prevent theft. The complete system includes a case of 10 boxes of pet waste bags. Each box contains 200 bags with the dimensions of 8"x 13" (20.3cm x 33cm). Finally, the package includes one mounting pedestal. This pedestal is made from 2"x 2" 14 gauge cold rolled steel and finished in grey rust proof paint.  The dispenser comes with a label reading "Pet Waste Station" which can be applied to the top of the dispenser if the end user wishes to do so. This label is shown in the product images.

Capacity

• The dispenser holds two boxes of disposable bags. Each box holds 200 bags. Total capacity is 400 bags.
• Disposal: 18.75 litres (4.1 imp gal, 5.4 US gal).
• Bag size is 8" x 13" (20.3cm x 33cm). 200 bags are in each individual box. A case includes 10 individual boxes. There are a total of 2,000 disposable bags in a case.

Materials

• Dispenser: 18 gauge steel with RAL super durable TGIC-free polyester powder coating which provides a rust proof finish.
• Bracket for the disposal: 18 gauge steel with RAL super durable TGIC-free polyester powder coating which provides a rust proof finish.
• Disposal: 100% recycled polyethylene, black finish.
• Pedestal: Vertical support is 2" x 2" cold rolled steel tubing (14 gauge).  Mounting plate is 1/8" cold rolled steel. Ground mounting plate is 1/4" cold rolled steel. All welded construction. Exterior grey polyester rust proof finish. Tested to survive harsh summer and winter weather.
• Consumable Bags: High density plastic bag, green in colour.
• Frost uses Super Durable TGCI-Free Powder Coat paint on all their site furnishings products. This type of powder coating is designed for superior weatherability compared to standard TGIC polyester powder coatings. This type of paint is designed to meet the AAMA (American Architectural Manufacturers Association) standard 2603. It provides excellent exterior color and gloss retention, superior over bake resistance, and good chemical resistance. The paint is designed to withstand 1500 hours of salt spray testing and 1 year of outdoor exposure in extreme conditions.

Product Dimensions

• 12″L x 7″D x 49″H (30.5cm L x 17.8cm D x 124.5cm H)

Product Weight

• 15.7 kg (34.7 lbs)

Installation

Secure disposal mounting bracket to pedestal using bolts (4), braces (2), and nuts (4) provided. Make sure the bracket for the disposal is in the unlocked position, then slide the black disposal into the top of the bracket first. The bottom of the disposal will then slide into the bracket and lock into place once the key is turned. Secure dispenser to the pedestal plate with bolts and nuts provided. Secure pedestal to ground with appropriate anchoring system for floor material. Use ground plate as a template to locate mounting holes. Drill holes and set anchors as required (not included). The installer will require a 5/16” wrench/socket and a #2 Robertson screw driver to attach the dispenser and disposal to the pedestal. The stainless steel bolts and nuts provided are ¼-20, 2” long bolts (quantity of 6) and ¼-20 lock nuts (quantity of 6). There are also two bolt plates for use with the disposal.

Maintenance

Normal preventative maintenance and cleaning will keep Frost products functioning properly and may extend normal product life. Products should be wiped down with a damp soft cloth periodically. Approved stainless steel cleaner may be used to clean scuffs or fingerprints on stainless surfaces. Do not use harsh detergents or chemical cleaners. For general dirt and blemishes on painted steel or plastic use warm water and mild soap, or a general mild cleaning solution. When using any type of cleaning solution, spray onto a discrete area to test before full usage. After the cleaning agent is applied, wipe off with a clean soft cloth or sponge.

Warranty

If any product or part proves to be defective within 12 months from date of shipment from the factory it will be repaired or replaced without any charge including freight costs when authorized. Costs resulting from the installation or removal of defective products are not covered under this warranty. Discolouration to stainless steel parts resulting from exposure to harsh environmental and / or chemicals are not considered to be defects in workmanship or material and are not covered under warranty.
